3D Move Eye KIWAMI ( MSY-AW09VF2 )
3D Move Eye KIWAMI
MSY-AW09VF2

 - LABEL EGAT NO.5 ( 5 Star)
The innovative design and advance technology to meet satisfy comprehensive uses, with coolness throughout the activation suitable for all the decoration.

สี : white

Download Catalog

Download
2D CAD
print
คุณสมบัติ
- LABEL EGAT NO.5 ( 5 Star)
- Inverter
Compressor operates silently and fluent, without cutting range, providing consistent cooling and energy saving.
- 3D Move Eye KIWAMI  The high efficiency of the temperatures and motion sensors to detect human presence and direct the cooling air to person automatically.
- Fast Cooling AI  The collaboration principle of both between 3D move-eye KIWAMI and fast cooling mode to evaluated  the temperatures and motion scanning. Adjusting the wind direction and temperature appropriately.
- Drive mode selector The operation can be switched 3 modes with one button. (Wide room mode/Sleep mode/Quiet mode)
- Plasma Quad Plus Increasing plasma power of air purifying system With the efficacy of 6 potencies is able to inhibit certain kinds of  viruses, the SAR-CoV-2 virus. Eliminates dust particles as small as 2.5 PM, inhibits allergens, etc.
- V Air Filter New dust filter. The specially designed molecular chemical coating, that has a reaction to eliminate viruses, common viruses, bacteria, molds, unpleasant odors, etc.
- Dual barrier coating chemical coating to minimize the dust capture, dust of fabric, oil mist and cigarette smoke on the 3 parts. (Squirrel cage blowers , air vent , evaporator panel)
- Dual barrier Material blended with special protection agents to reduce the dust capture, dust of fabric, oil mist and cigarette smoke on the air vents both parts.
- Quite Level Quiet operation only 19 dB.
- ERROR CODE (2-ways) check the abnormality of the air conditioner.
- Variable Airflow able to direct the air flow to both left and right sides independently simultaneously.
- Multi Flow Condenser (MFC) to increase the efficiency of heat exchange at the condensing panel and anti-corrosion.
- Set timer to automatically turn on/off 24 hours.
- R32 is an environmentally friendly refrigerant that does not harm the Earth's atmosphere.
Warranty 5 years warranty for Compressor. Warranty 3 years for evaporator panel and condensing. and 1 year for spare parts.
ในชีวิตประจำวันของผู้คน
MODEL
MSY-AW09VF2
Cooling capacity (BTU/h)
9,212
SEER (Btu/h/W)
26.48
EGAT level 5
5 STAR
Cooling : Capacity Rated (kW)
2.7 (1.0-3.6)
Heating : Capacity Rated (kW)
Power Supply
220 V. / Single Phese / 50 Hz
Microprocessor Control
Automatic Temperature Control
Timer Switch
4.66 / -
Remote Control Switch
Wireless
Indoor Fan Speeds
5+AUTO
Blow Fan Indoor
Line Flow Fan
Blow Fan Outdoor
Propeller
Dimensions Indoor (H x W x D)
305 x 998 x 247
Dimensions Outdoor (H x W x D)
550 x 800 x 285
Weight Indoor
14.4
Weight Outdoor
26.5
Piping Size : Liquid (mm.in)
6.35 (1/4)
Piping Size : Gas (mm.in)
9.52 (3/8)
Piping Size : Max.Length / Max.Height (m)
20/12
Refrigerant
R32
Warranty
3 Years IN/OUT door heat exchanger , 5 Years Compressor , 1 Year General Part.
