PC SERIES (PC-M36KAKL)
PC SERIES
PC-M36KAKL
สี : white

Download Catalog

Download
2D CAD
print
- Modern shape Beautiful design Save space on installation.
- Work quietly With the air channel design. And leaves a fan to thin. But it can cut a lot of air.
- Remote control with wireless remote control Or Wired (Option)
- SWING system helps to distribute cold air all over the room quickly.
- Can pipe solution Up to 30 - 50 meters.
- Can be centrally controlled or controlled in bulk. With automatic crash alert system.
MODEL
PC-M36KAKL
Cooling capacity (BTU/h)
36,167
SEER (Btu/h/W)
11.60
EGAT level 5
0
Cooling : Capacity Rated (kW)
10.60
Heating : Capacity Rated (kW)
Power Supply
1 ph, 220V, 50Hz
Microprocessor Control
Automatic Temperature Control
Timer Switch
Remote Control Switch
Wireless/Wired(Option)
Indoor Fan Speeds
4
Blow Fan Indoor
Blow Fan Outdoor
Dimensions Indoor (H x W x D)
230 x 1,600 x 680 (mm.)
Dimensions Outdoor (H x W x D)
981 x 1050 x 330 (mm.)
Weight Indoor
40
Weight Outdoor
81
Piping Size : Liquid (mm.in)
9.52 (3/8)
Piping Size : Gas (mm.in)
15.88 (5/8)
Piping Size : Max.Length / Max.Height (m)
50/30
Refrigerant
R32
Warranty
3 Years IN/OUT door heat exchanger , 5 Years Compressor , 1 Year General Part.
